Non-Contact Laser Wheel Aligner 3D Laser Measurement Rim Zero Damage Vehicle Four-Wheel Positioning Test Equipment
Non-Contact Laser Wheel Aligner is a new generation of high-end auto maintenance equipment replacing traditional clamp-based models. Adopting 3D laser imaging and high-precision industrial camera technology, it completes full-parameter four-wheel alignment tests in 30 seconds without installing clamps or targets and without contacting rims or tires. Equipped with wireless transmission and magnetic suction design, it is plug-and-play and factory-calibrated, compatible with sedans, SUVs, trucks and new energy vehicles, and suitable for scissor/four-post lifts. It can accurately measure core parameters such as toe, camber, caster angle and thrust angle, automatically generate test reports, and features zero rim damage, efficient operation and accurate stable data. Widely used in auto repair shops, 4S stores and inspection stations, it is a core equipment for vehicle alignment, fault diagnosis and driving safety assurance.
Description
This non-contact laser wheel aligner adopts German imported linear laser measurement system and 5-megapixel HD industrial camera. Through 3D laser imaging algorithm, it emits multiple groups of linear lasers to scan the tire surface, real-time constructs a three-dimensional wheel space model, and accurately calculates 10+ core alignment parameters such as toe, camber, caster angle, thrust angle, track width and wheelbase. The measurement accuracy reaches ±0.01° with minimal repeatability error and stable reliable data.
Subverting traditional contact design, no clamps or targets required, no contact with rims or tires, completely avoiding rim scratches and deformation risks, achieving zero rim damage. No pushing for eccentric compensation is needed; measurement starts once the vehicle is parked, completing full vehicle test in 30 seconds with over 80% efficiency improvement, greatly reducing labor costs. Adopting industry-leading magnetic modular design, it is plug-and-play with no on-site assembly or wiring required. Factory-calibrated for immediate use. Equipped with large-capacity removable lithium battery, it supports 8-hour wireless operation with no power connection needed during measurement, ensuring safety and convenience.
Compatible with 12-22 inch rims, it fits sedans, SUVs, MPVs, light trucks and pure electric/hybrid new energy vehicles, supporting 2WD/4WD vehicle testing. It can be flexibly matched with scissor lifts and four-post lifts, suitable for various auto repair workshop spaces. Equipped with a 15-inch HD touch console, it features a simple and intuitive operation interface, supporting standard/fast dual measurement modes, real-time display of test data and alignment curves, one-click PDF report generation, and data storage, traceability and printing for easy customer record management.
With additional steering wheel level calibration function, it accurately measures the steering wheel centering angle and guides suspension and steering system adjustment, solving problems such as vehicle pulling, off-center steering wheel and abnormal tire wear. Featuring anti-interference design, it operates stably regardless of workshop light and vibration. Strictly compliant with national standards such as GB/T 18565, it is the preferred efficient, accurate and durable four-wheel alignment equipment for auto repair shops, 4S stores and inspection stations.
